How to set up splash screen in flutter

Flutter, UI/UX

There are two ways to setup splash screen in flutter.

First, we need to update the launch_background.xml file location below:
android/app/src/main/drawable/launch_background.xml

1
2
3
4
5
6
7
8
9
10
11
12
<?xml version="1.0" encoding="utf-8"?>
<!-- Modify this file to customize your launch splash screen -->
<layer-list xmlns:android="http://schemas.android.com/apk/res/android">
    <item android:drawable="@android:color/white" />

    <!-- You can insert your own image assets here -->
    <!-- <item>
        <bitmap
            android:gravity="center"
            android:src="@mipmap/launch_image" />
    </item> -->
</layer-list>

If you want to change the splash screens’ background color, then you need to update the code as below:

1
2
3
4
5
6
7
8
9
10
11
12
<?xml version="1.0" encoding="utf-8"?>
<!-- Modify this file to customize your launch splash screen -->
<layer-list xmlns:android="http://schemas.android.com/apk/res/android">
    <item android:drawable="@android:color/black" />

    <!-- You can insert your own image assets here -->
    <!-- <item>
        <bitmap
            android:gravity="center"
            android:src="@mipmap/launch_image" />
    </item> -->
</layer-list>

If you want to add an image at the center of the splash screen, then you need to un-comment the code and place an image insde of drawable folder and change the android:src as below:

1
2
3
4
5
6
7
8
9
10
11
12
<?xml version="1.0" encoding="utf-8"?>
<!-- Modify this file to customize your launch splash screen -->
<layer-list xmlns:android="http://schemas.android.com/apk/res/android">
    <item android:drawable="@android:color/black" />

    <!-- You can insert your own image assets here -->
    <item>
        <bitmap
            android:gravity="center"
            android:src="@drawable/splashimage" />
    </item>
</layer-list>

Please note that do not write the image’s extension. Recommend to use png format of the image.

It is the first method to set up the splash screen in flutter.

The second method is to create a page for a splash screen and automatically goes to the main page when the time is up.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
import 'dart:async';

import 'package:flutter/material.dart';

void main() => runApp(MyApp());

class MyApp extends StatelessWidget {
  @override
  Widget build(BuildContext context) {
    return MaterialApp(
      title: 'Flutter Demo',
      theme: ThemeData(
        primarySwatch: Colors.blue,
      ),
      home: SplashScreen(),
    );
  }
}

class SplashScreen extends StatefulWidget {
  @override
  _SplashScreenState createState() => _SplashScreenState();
}

class _SplashScreenState extends State<SplashScreen> {
  @override
  void initState() {
    // TODO: implement initState
    Timer(Duration(seconds: 3), () {
      Navigator.push(
        context,
        MaterialPageRoute(
          builder: (context) => MyHomePage(title: 'Splash Screen Test'),
        ),
      );
    });
  }

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      body: Container(
        color: Colors.black,
        child: Center(
          child: CircleAvatar(
            backgroundColor: Colors.amberAccent,
            foregroundColor: Colors.red,
            child: Icon(
              Icons.adb,
              size: 50.0,
            ),
          ),
        ),
      ),
    );
  }
}

class MyHomePage extends StatefulWidget {
  MyHomePage({Key key, this.title}) : super(key: key);

  final String title;

  @override
  _MyHomePageState createState() => _MyHomePageState();
}

class _MyHomePageState extends State<MyHomePage> {
  @override
  Widget build(BuildContext context) {
    return MaterialApp(
      home: Scaffold(
        appBar: AppBar(
          title: Text(widget.title),
        ),
        body: Center(
          child: Column(
            mainAxisAlignment: MainAxisAlignment.center,
            children: <Widget>[
              Text(
                'Hello World',
              ),
            ],
          ),
        ),
      ),
    );
  }
}

This is what I’ve done.
